api.ast.fem

Functions

compute_diag_len(p, md, mc)
convert(dtype)	This function returns the index of a Function Space in a 3D DeRham sequence
expand(args)	This function expands vector functions into indexed functions
expand_hdiv_hcurl(args)	This function expands vector functions of type hdiv and hculr into indexed functions
get_degrees(funcs, space)
get_multiplicity(funcs, space)
regroup(tests)	This function regourps the test/trial functions by their Function Space
toInteger(a)

Classes

AST(expr, terminal_expr, spaces, *, nquads)	The AST class transforms a terminal expression returned from SymPDE into a DefNode object, which it stores into the attribute expr.
DefNode(name, arguments, local_variables, ...)	DefNode represents a function definition where it contains the arguments and the body

Details

toInteger(a)

convert(dtype)

This function returns the index of a Function Space in a 3D DeRham sequence

compute_diag_len(p, md, mc)

regroup(tests)

This function regourps the test/trial functions by their Function Space

expand(args)

This function expands vector functions into indexed functions

class DefNode(name, arguments, local_variables, body, imports, results, kind, domain_dtype='real')

Bases: Basic

DefNode represents a function definition where it contains the arguments and the body

property name

property arguments

property local_variables

property body

property imports

property results

property kind

Default kind for all SymPy object. If the kind is not defined for the object, or if the object cannot infer the kind from its arguments, this will be returned.

Examples

>>> from sympy import Expr
>>> Expr().kind
UndefinedKind

property domain_dtype

This property is used when we create the type of a constant for pyccel in build_pyccel_types_decorator.

default_assumptions = {}

expand_hdiv_hcurl(args)

This function expands vector functions of type hdiv and hculr into indexed functions

get_multiplicity(funcs, space)

get_degrees(funcs, space)

class AST(expr, terminal_expr, spaces, *, nquads, mapping_space=None, tag=None, mapping=None, is_rational_mapping=None, num_threads=1, **kwargs)

Bases: object

The AST class transforms a terminal expression returned from SymPDE into a DefNode object, which it stores into the attribute expr.

A DefNode represents a function definition, and it contains the full PSYDAC abstract syntax tree for the assembly function of a BilinearForm, LinearForm, or Functional.

property expr

property nderiv

property domain

property mapping

property dim

property num_threads
